应用   Application
医药、食品、化工等行业进行以下物料干燥
◎  适用于浆状、膏糊状、粉状物料。
◎  要求低温干燥的热敏性物料。
◎  易氧化、易爆、强刺激、剧毒物料。
◎  要求回收有机溶剂的物料。

The following raw materials from pharmaceutical industry, food-stuff industry, chemical industry and so on can be dried.
◎  Suitable for pulpiness, paste-like mixture of powder raw materials.
◎  Thermal sensitive raw materials having the requirement to dry at lower temperature.
◎  Raw materials that are easy to oxidized or explode and have strong irrtative or toxic.
◎  Raw materials that need to recover solvent.
----------------------------------------------------------------------------------------------------------------
特点   Features
◎  本机采用夹层与内搅拌同时加热方式，传热面大，热效率高。
◎  本机设置搅拌，使物料在筒内形成连续循环状态，进一步提高了物料受热的均匀度。
◎  本机设置搅拌，从而可顺利进行浆状、膏状、糊状物料干燥。

◎  Being adapted the heating way of jacket and inner stirring at the same time,its heat conducting area is large and its heat efficiency is high.
◎  Being installed stirring in the machine, it makes raw material in the cylinder form the state of continuous circle inside the cylinder, so the uniformity to be heated of raw material is raised greatly.
◎  Being installed stirring apparatus in the machine, pulpiness, pastelike mixture or powder raw materials can be dried easy.
----------------------------------------------------------------------------------------------------------------
技术参数   Technical parameters

项目 Item  　  机型 type
单位 unit  ZB-500  ZB-750  ZB-1000  ZB-1500  ZB-2000  ZB-3000  ZB-5000
名称 Name
工作容积
Working volume  L  300  450  600  900  1200  1800  3000
内简尺寸
over in the cylinder  Mm  Φ600×1500  Φ800×1500  Φ800×2000  Φ1000×2000  Φ1000×2600  Φ1200×2600  Φ1400×3400
搅拌转速
Stirring  revolution  rpm  7~6
功率 Power  kw  4  5.5  5.5  7.5  11  15  22
夹层设计压力 Design pressure of jacket  MPa  0.3
筒内压力
Pressure in the cylinder  Mpa  -0.096～-0.15
注：水份蒸发量与物料的特性及热风进、出口温度有关。随着产品不断更新，有关参数变更，恕不预先通知。
Notes:the evaporated amount of water its related to the characteristics of raw materials and the temperature of air in and air out. With renew products unceasingly, the related parameters will be exchanged, it does not a
