Optical polishing applications rely on specific geometry. The OptiPrep™ features a fixed cam-lock interface reference that is parallel to the plane of the platen. Desired sample angles are obtained based on geometric orientation built into the fixture.
Z-positioning/indexing is displayed on the digital indicator with 1-micron resolution， and can be pre-set for unattended operation. Variable speed rotation/limit rotation and oscillation with variable sweep maximize use of the entire abrasive surface.
Adjustable load control expands its capability to handle a range of small (delicate) to large samples.
Applications where the OptiPrep™ is used often require custom fixtures. Please contact Allied for assistance with a current fixture or to design and manufacture a fixture for a complete solution.
| Variable platen speed: 5-350 RPM， in 5 RPM increments | Touch pad switches control all functions | |
| ? HP (190 W) DC motor with durable reduction gearbox provides constant high-torque output | Digital timer and tachometer | |
| Integrated controls for operation of the OptiPrep™ Positioning Device | Clockwise/counterclockwise platen rotation | |
| Quick-change platen design， anodized to resist wear and corrosion | Corrosion/impact resistant cover | |
| Bowl flush to prevent debris build-up | Electronic coolant control with adjustable valve |
OptiPrep Positioning Device
| Front digital indicator displays real-time material removal/sample advancement | Rear digital indicator displays vertical positioning (static) with zeroing function， 1 micron resolution | |
| Precision spindle design indexes sample perpendicular to the platen， and can rotate simultaneously | Automatic sample oscillation， adjustable sweep with 6 speeds | |
| Full or limited automatic sample rotation with 8 speeds | Cam-locking system eliminates the need for tools and allows for exact repositioning of fixtures | |
| Dimensions: 15" W x 26" D x 20" H (381 x 660 x 508 mm) | Weight: 95 lb. (43 kg) | |
| Shipping Dimensions: 33" W x 31" D x 15" H (838 x 787 x 381 mm) | Shipping Weight: 125 lb. (57 kg) | |
| Two (2) year warranty | CE Compliant | |
| Designed & manufactured by Allied in the USA |
